Ground Anchor - Lateral

Our Ground Anchors are designed to dissipate angular moment loads with unilateral and multilateral fins making them well suited to secure poles, and tents or other temporary structures. They use the same ½" drive system as the Deck Foot Anchor™ for fast and easy installation and removal.

Includes a single auger, eye nut with fin. Auger drives into virtually all soil with hand held impact wrench. Or use our  Auger hand tool to install by hand. Fin is driven with a 3lbs hammer. Cables sold separately.

Available in 36" or 48" lengths.

The 3-¼" blade and 5" blade have tested in clay for maximum compression loads of 1,391# and 5,500# respectively.

$64.97
Ground Anchor Load Fin (Load Fin): Unilateral
Deck Foot Auger Only (Auger Length): 36" 3-¼" Blade
Ground Anchor Load Fin (Load Fin): Unilateral / Deck Foot Auger Only (Auger Length): 36" 3-¼" Blade

Stock Notification

Get notified when this product is available again

Frequently Bought Together

American Express
Apple Pay
Discover
Google Pay
Mastercard
PayPal
Visa

Recommended for You

Warning: Rocks, roots, or a weak impact wrench (we recommend a corded 350 ft-lbs DeWalt) may prevent you from driving the auger fully into the soil. Use only a 6 point socket as a 12 point socket may strip the driver head. To test your soil for auger suitability, use a 3/4" spade bit with a 24" bit extender and try driving it into your soil. This will give you a good indication of this system will work in your location.


UNILATERAL


This assembly incorporates a single resistance panel designed for applications where assumed forces will exist along a single plane perpendicular to the panel.


If your application is subject to these kinds of forces, the Unilateral Fin is likely the right solution.



MULTILATERAL


This assembly incorporates two criss crossing resistance panels and is better suited for applications where forces may exist in a variety of directions.


The Multilateral Fin is a more robust assembly and better suited for applications where one or more cables may be secured to it.


COMMON USES


Tents or other temporary structures can be held secure using either a Unilateral or Multilateral Fin assemblies depending on your preference.


The Multilateral Fin will generally perform better where forces may be shifting over time. However the Unilateral Fin may be sufficient for your application.

UPLIFT

Pull out resistance (tension) from undisturbed soil varies by soil type and auger length.  If you are building a project where known uplift data is required please see our Tension Test data for sandy or clay soils based on auger length.  This is data taken from field testing by Intertek in a location in Colorado and is part of an extensive residential code compliance review program this is expected to be completed in the spring of 2022.

FLEXIBLE SHIPPING

EASY RETURNS

SUPPORT 24/7

Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
J
Jan G.
I am a potter, and

I am a potter, and on the advice of a very helpful DecksGo employee, we used this piece of hardware to anchor a ceramic totem into the ground. It was the perfect thing. So happy and grateful!
